Model：WX-SY1
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
1. Product Introduction
The integrated porous water pressure automatic monitoring station (SY1 type) is used to monitor the seepage pressure of different geological strata in the landslide body in real time. Its main components are all made of special steel, suitable for use in various harsh environments. In particular, after the cable protection measures are perfected, it can be directly buried in the roller-compacted concrete with high requirements for the instrument.
Monitoring data is transmitted to the monitoring and early warning cloud service platform through communication methods such as full network communication/GPRS/Beidou satellite.
Second, product features
Integrated structure, small volume, no need for integration, easy to install
Support multiple power supply modes
Can automatically identify the communication card number and upload it to the background server
Remote and local setting of the early warning threshold support system
With RS485 and RS232 interfaces
Support full network/ GPRS/ Beidou satellite and other communication methods for data transmission
CS architecture software platform, supports mobile phones, PC browsers to directly observe, no need for additional software installation.
Support multiple accounts, multiple devices login
Support for real-time data display and historical data display dashboard
Cloud server, cloud data storage, stable and reliable, easy to expand, load balancing.
Support for map display, view device information.
Support data curve analysis
Support data export in table format
Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.
Support for data post-processing functions
Support for external JavaScript scripts
Three, Product Parameters
| Equipment name | Technical indicators | Technical parameters |
| Pressure sensor | Measuring medium | Water and non-corrosive liquids |
| Range of measurement | 0-1000KPa | |
| Overload pressure | 1.5 times the full scale reading | |
| Stable drift | 0.03%F.S/℃ | |
| Work environment | -10-50℃, non-corrosive measuring environment for stainless steel | |
| Precision | 0.5 accuracy level | |
| Power supply system | Solar panels | Monocrystalline silicon 30W (can be customized according to the site conditions) |
| Battery | 20AH (can be customized according to the site conditions) | |
| Protection box | Material | Stainless steel corrosion-resistant and corrosion-resistant material, used for protecting built-in equipment |
| Integrated mounting bracket | Selection | Carbon steel support |
| Acquisition terminal | Support RS485/RS232/GPRS and other interfaces | |
