Model：WX-SQ15
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
The wearable handheld meteorological instrument provides real-time measurements of temperature, humidity, atmospheric pressure, wind speed, direction, lighting, total radiation, ultraviolet radiation, runway temperature and other parameters, and has outdoor SOS distress, electronic compass, runway temperature, NSS positioning and other functions
1. Wearable handheld meteorological instrument Product Introduction
This product provides real-time measurement of parameters such as temperature, humidity, atmospheric pressure, wind speed, wind direction, light, total radiation, ultraviolet radiation, runway temperature, etc.a
It also has functions such as outdoor SOS rescue, electronic compass, runway temperature, weather forecast for the next 3 hours, human comfort, radio silence, GNSS positioning, etc.
At the same time, wireless transmission ( 4GCat1) and WiFi upload to cloud platform or local area network server are realized, and USB can read internal storage data.
This instrument can be widely used in meteorology, environmental protection, airports, agriculture and forestry, hydrology, military, warehousing, scientific research and other fields.
2. Wearable handheld meteorological instrument Technical Parameters
Meteorological parameters | Measuring features | Measuring range | Accuracy | Resolution | unit |
temperature | -45-130 | ±0.2 | 0.01 | ℃ | |
humidity | 0-100 | ±2.0 | 0.01 | % | |
Atmospheric pressure | 30-110 | ±0.01 | 0.01 | KPa | |
Wind speed | 0-40 | ±1 | 0.01 | m/s | |
wind direction | 0-359 | ±1 | 1 | ° | |
illumination | 0-157286 | ＜±3% | 1 | Lux | |
UV rays | 0-1242 | ＜±3% | 1 | W/㎡ | |
Total radiation | 0-262144 | ＜±3% | 1 | mW/㎡ | |
Runway temperature | - 40- 85 | ±0.5 | 0.01 | ℃ | |
Electronic compass | 0-359 | 1 | 1 | Spend | |
GNSS positioning | Positioning accuracy 2m | ||||
SOS | International Morse Code distress signal | ||||
Battery | 3800mAh | ||||
Communications | 4G Cat1, Wifi, USB | ||||
Radio Silence | Disable device 4G CAT1 communication and enter airplane mode | ||||
Human comfort | Calculate the current human comfort level based on the SET model | ||||
Next 3 hours Weather forecast | Deduces three-hour weather conditions based on temperature, humidity, atmospheric pressure, light, ultraviolet rays, wind speed and other information | ||||
storage | 6MB storage (90,000 records) | ||||
Host size | 160*62*40 mm | ||||
working environment | -20℃～80℃; 5%RH～95%RH | ||||
3. Configuration Instructions
4. Product appearance
5. Product size diagram
6. Shipping List
name | quantity |
Host | 1 |
charger | 1 |
Data cable | 1 |
manual | 1 |
Certificate | 1 |
Warranty Card | 1 |
Packing box | 1 |
