Model：WX-NQ10
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
1. Product Introduction
NQ10 Agricultural Weather Station is a highly integrated, low-power, quick-to-install, and easy-to-use field monitoring weather observation device with high precision.
The device consists of five parts: meteorological sensor, collector, solar power supply system, vertical bracket, and cloud platform. It is easy to use and can be quickly deployed, widely used in meteorology, agriculture, forestry, scientific research, and other fields.
2. Product features
1. Low power sensor node: static power consumption less than 50uA
2. Standard GPRS connectivity, supports extended Bluetooth, wired transmission
3. 7-inch Android touch screen, version: 4.4.2, four-core Cortex?-A7, 512M/4G
4. Support modbus485 sensor extension
5. Solar charging management MPPT automatic power point tracking
6. Three-meter carbon steel support, two sections of thread connection.
7. SMS alarm, sending a message to a specified mobile phone after exceeding the limit
8.Stainless steelMaterial protection box, corrosion-resistant, anti-oxidation, waterproof grade IP66
Three, Technical Parameters
1. Collector power interface: GX-12-3P plug, input voltage 5V, with RS232 output Json data format, collector power: DC5V ±0.5V peak current 1A,
2. Sensor modbus, 485 interface: GX-12-4P plug, output supply voltage 12V/1A, device configuration interface: GX-12-4P plug, input voltage 5V
3. Solar power supply, with lead-acid battery configuration, optional 30W 20AH/50W 20AH/100W 100AH. Charging controller: 150W, MPPT automatic power point tracking, 20% efficiency improvement.
4. Data upload interval: 1 minute - 1000 minutes adjustable
5. Screen size: 1024*600 RGB LCD
6. Partial sensor parameters
| Name | Measurement range | Resolution | Accuracy |
| Ambient temperature | -40～+80℃ | 0.01℃ | ±0.3℃ (25℃) |
| Relative humidity | 0～100%RH | 0.01%RH | ±3%RH (20%~80%) |
| Irradiance | 0-157286LUX | 1Lux | ±3% |
| Atmospheric pressure | 300-1100hpa | 0.1 hPa | ±0.25% |
| Dew point temperature | 0~+70℃ | 0.1℃ | ±1℃ |
| Tubular soil temperature | -30～+70℃ | 0.01℃ | ±0.3(-10~70℃) |
| Tubular soil moisture | 0 to 100% | 0.1% | ±3% |
| Tubular soil salinity | 0~20000us/cm | 1us/cm | ±3 (0~10000us/cm) ±5% (full scale) |
| Soil PH (Electrode Method) | 0-14PH | 0.01 | ±0.1PH |
| Soil nitrogen phosphorus potassium | 0~1999mg/kg | 1 mg/kg | ±2% |
| Soil evaporation | 0～75mm | 0.1mm | ±1% |
| Wind direction | 0-360 degrees | 0.1 degree | ±1 degree |
| Wind speed | 0-60m/s | 0.01m/s | ±0.2m/s |
| Average wind speed☆ | 0-60m/s | 0.01m/s | ±0.2m/s |
| Rainfall | ≦4mm/min | 0.2mm | ≤±2% |
| Ultraviolet radiation | 0～500W/㎡ | 0.01W/m2 | ≤±3% |
| Hours of sunshine | 0～6500h | 0.1 h | ＜0.2 h |
| Photoelectric total radiation | 0-2000W/m2 | 1W/m2 | ±3% |
| Photosynthetically active radiation | 0-2000W/m2 | 1W/m2 | ≤±5% |
| Carbon dioxide | 400-5000ppM | 1ppM | ±(50ppm+5% of reading) |
| PM2.5 | 0-1000ug/m3 | 1ug/m3 | ±10% ( < 500 micrograms ) |
| PM10 | 0-1000ug/m3 | 1ug/m3 | ±10% ( < 500 micrograms ) |
| Carbon monoxide | 0-1000ppm | 1PPM | ±2PPM |
| Sulfur dioxide | 0-20PPM | 0.1PPM | ±1PPM |
| Nitrogen dioxide | 0-20PPM | 0.1PPM | ±1PPM |
| Ozone | 0-20PPM | 0.1PPM | ±1PPM |
| Negative oxygen ions | 0～100,000 particles/cm3 | 1 per/cm3 | Reading ±10%; Ion mobility ≤ ±20% |
| Oxygen content | 0~25%Volume | 0.1% | ±3%FS |
Four, Cloud Platform
1. CS architecture software platform, supports mobile phones, PC browsers to observe directly, no need to install additional software.
2. Support multiple accounts, multiple devices login
3. Support for real-time data visualization and historical data visualization dashboards
4. Cloud servers, cloud data storage, stable and reliable, easy to expand, load balancing.
5. Support for SMS alarm and threshold setting
6. Support for map display, view device information.
7. Support data curve analysis
8. Support for exporting data in table format
9. Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.
10. Support for data post-processing functions
11. Support for external JavaScript scripts
