Model：WX-SQ5B
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
1. Handheld intelligent weather station Product Introduction
The device can observe wind speed, wind direction, temperature, humidity and air pressure in real time, and can realize 24-hour continuous online monitoring of outdoor meteorological parameters . The built-in display screen is a touch screen, and data upload is achieved in seconds. Multiple parameters are output to the user at one time through the digital communication interface. The device does not require debugging and can be deployed quickly. It is widely used in wind power measurement, ocean monitoring, defense support, airport monitoring, high-voltage power transmission monitoring, road and bridge monitoring, scientific research and other fields. Under the current situation, we are ready for domestic substitution.
2. Handheld intelligent weather station Technical Parameters
name | Five Elements Handheld Weather Meter | model | WX-SQ5B | ||
Serial number | Elements | scope | Resolution | Accuracy | |
1 | Wind speed | 0～60m/s | 0.1m/s | ±3% | |
2 | wind direction | 0～360° | 0.1° | ±2° | |
3 | temperature | -55～85℃ | 0.1° | ±0.3℃ | |
4 | humidity | 0～100%RH | 0.1%RH | ±3%RH | |
5 | Air pressure | 300～1200hPa | 0.1hPa | ±0.5hPa | |
6 | LCD screen temperature | -30～85℃ | Customizable ultra-low temperature screen | ||
7 | Backlight adjustment | adjustable | 10 minutes screensaver | ||
8 | data storage | 1 year | 1 minute | -- | |
9 | Data output | Data can be read online | |||
10 | Automatic north search | Enable | Calibration possible | Can be disabled | |
11 | Battery life | Low power consumption 30 hours | Maximum power consumption 22 hours | ||
12 | weight | 1.78Kg | |||
13 | physical dimension | 400mm x 156mm | |||
14 | tripod | Instantaneous wind resistance 20m/s | |||
15 | Carrying case | High-strength trolley case | |||
